| Seats | One Seater, Two Seater, Three Seater, Four Seater, Five Seater |
|---|---|
| Seat Colour | Black, Blue, Burgundy |
Recepetion
Polypropylene Reception Unit
Dimensions
| RBTU13-S1 | RBTU13-S2 | RBTU13-S3 | RBTU13-S4 | RBTU13-S5 | |
| Overall Height | 960mm | 960mm | 960mm | 960mm | 960mm |
| Overall Width | 525mm | 1105mm | 1585mm | 2115mm | 2645mm |
| Overall Depth | 650mm | 650mm | 650mm | 650mm | 650mm |
| Total Weight | 18kg | 21kg | 24kg | 28kg | 33kg |
| Overall Height | 480mm | 480mm | 480mm | 480mm | 480mm |
Specifications
Foot
76 x 25mm Rectangular tubing – Cold rolled steel with 3mm wall thickness
Leg
50mm Square tubing – Cold rolled steel with 2mm wall thickness
Beam
50mm Square tubing – Cold rolled steel with 2mm wall thickness
Seat and Back Supports
22.23mm Square tubing – Cold rolled steel with 1.6mm wall thickness
Seat
Injection moulded polypropylene
Available in black, blue or burgundy
Back
Injection moulded polypropylene
Available in black, blue or burgundy
